Bit Error Probability Analysis for Massive MIMO Wireless Communications utilizing Zero Forcing Precoding

Article Sidebar

PDF
Published: Jun 2, 2026
Keywords:
Massive Multiple-Input Multiple-Output, Zero forcing precoding and Rayleigh fading channel

Main Article Content

Ditsapon Chumchewkul
Department of Telecommunication Engineering, Faculty of Engineering, Rajamangala University of Technology Rattanakosin, Salaya campus, Thailand

Abstract

This article derives bit error probability (BEP) for massive multiple-input, multiple-output (M-MIMO) wireless communication, utilizing zero-forcing precoding. Frequency-flat fading channel is focused on this research work. The author utilizes the first-order Neumann series to analyze a closed-form expression for the normalization factor of the M-MIMO system, and proves that the probability distribution function (PDF) for the effective noise approaches the Gaussian distribution. A closed-form expression for the variance is additionally analyzed, and the derived PDF is then chosen to analyze the BEP for the M-MIMO system, utilizing B/QPSK (Binary/Quadrature phase shift keying) and 𝑀-QAM (𝑀-ary Quadrature amplitude modulation), with Gray-coded mapping. The analytical results are validated through Monte-Carlo simulation, and the empirical results confirmed that the derived BEP significantly matched the exact results. Focusing on a system with 512 transmit antennas and 20 users, the derived BEP for 16-QAM at ðļ𝑏/𝑁0 = -5 dB was 4 × 10-3, and the deviation between the analysis and the exact BEP was only 4.78 × 10-6. Thus, the proposed BEP analysis can be utilized for analyzing performance of M-MIMO system efficiently.

Article Details

How to Cite
[1]
D. Chumchewkul, “Bit Error Probability Analysis for Massive MIMO Wireless Communications utilizing Zero Forcing Precoding”, TEEJ, vol. 6, no. 2, pp. 8–15, Jun. 2026.
Issue
Vol. 6 No. 2 (2026): May - August
Section
Research article
Creative Commons License

This work is licensed under a Creative Commons Attribution-NonCommercial-NoDerivatives 4.0 International License.

Journal of TCI is licensed under a Creative Commons Attribution-NonCommercial-NoDerivatives 4.0 International (CC BY-NC-ND 4.0) licence, unless otherwise stated. Please read our Policies page for more information...

References

C. -X. Wang, et. al., "On the Road to 6G: Visions, Requirements, Key Technologies, and Testbeds," IEEE Commun. Surv. Tut.,

vol. 25, no. 2, pp. 905-974, 2023.

N. Fatema, G. Hua, Y. Xiang, D. Peng and I. Natgunanathan, "Massive MIMO Linear Precoding: A Survey," IEEE Syst. J., vol.

, no. 4, pp. 3920-3931, 2018.

M. A. Albreem, A. H. A. Habbash, A. M. Abu-Hudrouss and S. S. Ikki, "Overview of Precoding Techniques for Massive MIMO,"

IEEE Access, vol. 9, pp. 60764-60801, 2021.

F. Rusek et al., "Scaling Up MIMO: Opportunities and Challenges with Very Large Arrays," IEEE Signal Process. Mag., vol. 30,

no. 1, pp. 40-60, 2013.

J. Hoydis, S. T. Brink and M. Debbah, "Massive MIMO in the UL/DL of Cellular Networks: How Many Antennas Do We Need?,"

in IEEE J. Sel. Areas in Commun., vol. 31, no. 2, pp. 160-171, 2013.

H. Falconet, L. Sanguinetti, A. Kammoun and M. Debbah, "Asymptotic Analysis of Downlink MISO Systems Over Rician Fading Channels," in Proc. IEEE Int. Conf. Acoustics Speech Signal Process., pp. 3926-3930, 2016.

R. Yao, T. Li, Y. Liu, X. Zuo and H. Liu, "Analytical Approximation of the Channel Rate for Massive MIMO System With Large But Finite Number of Antennas," IEEE Access, vol. 6, pp. 6496-6504, 2018.

C. Zhang, Y. Jing, Y. Huang and L. Yang, "Performance Analysis for Massive MIMO Downlink With Low Complexity Approximate

Zero-Forcing Precoding," IEEE Trans. Commun., vol. 66, no. 9, pp. 3848-3864, 2018.

J. K. N. Nyarko, J. Xie, R. Yao, Y. Wang and L. Wang, "Accurate Approximation of ZF Massive MIMO Channel Rate With a Finite

Antenna Over Ricean Fading Channel," IEEE Access, vol. 6, pp. 65803-65812, 2018.

Q. -U. -A. Nadeem and A. Chaaban, "Analysis of One-Bit Quantized Linear Precoding Schemes in Multi-Cell Massive MIMO Downlink," IEEE Trans. Commun., vol. 72, no. 5, pp. 2577-2594, 2024.

L. G. Ordonez, D. P. Palomar, A. Pages-Zamora and J. RodrÍguez Fonollosa, "Minimum BER Linear MIMO Transceivers With

Adaptive Number of Substreams," in IEEE Trans, Signal Process., vol. 57, no. 6, pp. 2336-2353, 2009.

L. Zhao, K. Zheng, H. Long, H. Zhao, “Performance Analysis for Downlink Massive MIMO System With ZF Precoding”, in Proc.

Trans. Emerging Telecom. Technol., 2013.

S. Jacobsson, G. Durisi, M. Coldrey and C. Studer, "Linear Precoding With Low-Resolution DACs for Massive MU-MIMOOFDM Downlink," in IEEE Trans. Wireless Commun., vol. 18, no. 3, pp. 1595-1609, 2019.

M. Wu, B. Yin, G. Wang, C. Dick, J. R. Cavallaro and C. Studer, "Large-Scale MIMO Detection for 3GPP LTE: Algorithms and

FPGA Implementations," IEEE J. Sel. Topics Signal Process., vol. 8, no. 5, pp. 916-929, 2014.

R. S. Kshetrimayum, Fundamental of MIMO Wireless Communications, Cambridge, UK: Cambridge university press, 2017.

D. Chumchewkul and C. C. Tsimenidis, “Closed-Form Bit Error Probability of ZF Detection for OFDM-M-MIMO Systems Using

Effective Noise PDF,” IEEE Access, vol. 10, pp. 104384-104397, 2022.

A. Papoulis and S. U. Pillai, Probability, Random Variables, and Stochastic Processes, London: McGraw-Hill, 4th ed., 2002.

J. G. Proakis, Digital Communications. New York, USA: McGrawHill, 4th ed., 2001.

The GCC team, “GCC, the GNU Compiler Collection.” [Online]. Available: https://gcc.gnu.org/. [Accessed: Feb. 24, 2026].

C. Sanderson and R. Curtin, “Armadillo: An Efficient Framework for Numerical Linear Algebra,” in Proc. Int. Conf. Computer

Autom. Eng., 2025.

Python software foundation, “Welcome to Python.org.” [Online]. Available: https://www.python.org. [Accessed: Feb. 24, 2026].
