Application of a Thermosiphon-Tube Drying Chamber with Waste Heat from a Charcoal Kiln
Keywords:
Thermosiphon, Drying Chamber, Waste Heat, Turmeric Drying, Energy EfficiencyAbstract
Background and Objectives: Energy efficiency and sustainability are key issues in agriculture and industry, particularly in charcoal production processes where a large amount of heat is wasted. Recovering and reusing the heat in such processes as drying, which often face a problem related to energy efficiency, leading to high energy consumption and long drying time, represents an interesting alternative to the problem. The present study focused on the development and application of a thermosyphon drying chamber that utilizes waste heat from a charcoal kiln to improve the drying efficiency. The thermosyphon drying system drew heat directly from the kiln and effectively transferred it to the drying chamber. The objectives of this research were: (1) to design and develop a thermosyphon drying chamber and (2) to evaluate the heat distribution efficiency and its effects on product quality. The study also examined the potential of thermosyphon technology to optimize drying conditions, ensuring better energy conservation while maintaining product integrity.
Methodology: The study involved the design and development of a thermosiphon drying chamber, which consists of a drying compartment and a combustion chamber. The thermosiphon system used 30 stainless steel heat pipes filled with R134a refrigerant as the working fluid to facilitate passive heat transfer. Experiments were conducted using fresh turmeric as the test material; turmeric was made into slices of different thicknesses (2, 4, and 6 mm). The drying efficiency was assessed by measuring moisture loss, water activity (aw) and color changes at 90, 120 and 150 min. Thermal efficiency measurement was also made to compare the heat retention capacity of the system with that of a conventional drying chamber.
Main Results: Drying turmeric using the thermosyphon (TS) system increased moisture loss from 64.97% (No TS) to 80.43% at 90 min of drying (2 mm thickness) and reduced water activity (aw) from 0.91 to 0.75 at the same time. Extending the drying time to 150 min further decreased aw to 0.63 (TS), while in the No TS system it remained higher at 0.87. In a hypothetical feasibility comparison, TS system enabled 2 drying cycles per day, compared to 1 cycle in the case of No TS, thereby increasing the amount of fresh turmeric that can be processed in a day from 10 kg/day to 20 kg/day; these amounts resulted in the increased yield of dried turmeric from 1.8 kg/day to 3.6 kg/day. The total income increased from 270 to 540 baht/day. Although the initial cost of the TS system was higher (9,000 Baht compared to 6,000 Baht), TS system demonstrates strong potential for increasing productivity and income.
Conclusions: Thermosyphon drying chamber utilizing waste heat from a charcoal kiln could enhance the heat transfer efficiency and reduce the drying time of turmeric more effectively than a conventional system. However, aw values that still exceeded the safety threshold highlight the limitation of the system for turmeric drying. Nevertheless, the technology may be more suitable for other herbs with different structural characteristics. Improvements in temperature and airflow control are recommended. The system shows potential for applications ranging from household to industrial scale and could help reduce the reliance on conventional energy sources in the processing of agricultural products.
Practical Application: Thermosyphon drying system can be integrated into agricultural and industrial drying operations to improve energy efficiency and reduce operating costs. The ability to utilize waste heat from a charcoal kiln makes it a sustainable option for postharvest processing, benefiting farmers and small-scale producers. Furthermore, its low-maintenance design and reduced reliance on electric heating make it an economically viable choice for remote areas with limited resources. Additionally, the low-maintenance design and reduced dependency on electrical heating elements make it an economically viable solution for remote and resource-limited areas.
References
Pereira, A.K.S., Cupertino, G.F.M., da Silva, Á.M., Oliveira, T.R., de Souza, M.P., Delatorre, F.M. and Dias Júnior, A.F. 2023. Perspectives and challenges of world charcoal production in technological, social, and climate change fields. Forest Science: Sustainable Processes and Wood Products, 1, 1–23.
Tang, M., Li, G., Zhang, M., Zhou, X., Cai, K., Hu, S., Wu, L. and Cao, W. 2025. Comprehensive analysis and optimization of waste heat recovery and utilization in paper drying process. Energy, 325, 136084.
Agathokleous, R., Bianchi, G., Panayiotou, G., Aresti, L., Argyrou, M.C., Georgiou, G.S., Tassou, S.A., Jouhara, H., Kalogirou, S.A., Florides, G.A. and Christodoulides, P. 2019. Waste heat recovery in the EU industry and proposed new technologies. Energy Procedia, 161, 489-496.
Kalogirou, S.A. 2009. Solar water heating systems (pp. 251-314), in Solar Energy Engineering, Elsevier.
Nemec, P. and Malcho, M. 2015. Visualization of working fluid flow in gravity assisted heat pipe. EPJ Web of Conferences, 92, 02053.
Kravets, V., Shepel, H., Hurov, D. and Danylovich, A. 2024. Influence of geometric factors on the heat transfer characteristics of two-phase thermosyphons. Technology and Design in Electronic Equipment, 1–2, 43–48.
Sutanto, B., Indartono, Y.S., Wijayanta, A.T. and Iacovides, H. 2022. Enhancing the performance of floating photovoltaic system by using thermosiphon cooling method: Numerical and experimental analyses. International Journal of Thermal Sciences, 180, 107727.
Tamuli, B.R. and Choudhury, P.K. 2020. Comparative performance assessment of a solar hybrid dryer with traditional drying techniques (pp. 351-360), in Advances in Energy Research, Vol. 2, Springer, Singapore.
Yao, Y., Pang, Y.X., Manickam, S., Lester, E., Wu, T. and Pang, C.H. 2022. A review study on recent advances in solar drying: Mechanisms, challenges and perspectives. Solar Energy Materials and Solar Cells, 248, 111979.
Menon, A., Stojceska, V. and Tassou, S.A. 2020. A systematic review on the recent advances of the energy efficiency improvements in non-conventional food drying technologies. Trends in Food Science & Technology, 100, 67–76.
He, Y., Hu, C., Li, H., Hu, X. and Tang, D. 2022. Experimental investigation on air- cooling type loop thermosyphon thermal characteristic with serpentine tube heat exchanger. International Journal of Refrigeration, 138, 52–60.
Krishnan, S. and Sivaraman, B. 2017. Effect of slice thickness on quality of dried products in a solar cabinet dryer. American-Eurasian Journal of Sustainable Agriculture, 11, 7–13.
Cherdpant, W. and Ayus, W. 2001. Environmental impact of refrigerants in automobiles. Proceedings of the Air Conditioning Engineering Association, Department of Mechanical Engineering, Faculty of Engineering, Chulalongkorn University, 1–10. (In Thai)
Bezbah, I., Zykov, A., Mordynskyi, V., Osadchuk, P., Phylipova, L., Bandura, V., Yarovyi, I. and Marenchenko, E. 2022. Designing the structure and determining the mode characteristics of the grain dryer based on thermosiphons. Eastern-European Journal of Enterprise Technologies, 2, 54–61.
Takeshi, Y., Omi, Y. and Miura, K. 2019. “Thermosiphon-Type Temperature Control Device,” WO Patent No. 2019087574A1, World Intellectual Property Organization [Online]. Available: https://patents.google.com/patent/WO2019087574A1. [15 July 2025].
Nukulwar, M.R. and Tungikar, V.B. 2020. Thin-layer mathematical modeling of turmeric in indirect natural conventional solar dryer. Journal of Solar Energy Engineering, 142, 041001.
Erlikhman, V.N. and Fatykhov, Yu.A. 2018. The account of water activity in the calculation of the rate of food product shrinkage. Proceedings of the Voronezh State University of Engineering Technologies, 80, 18-21.
Majid, D., Sofi, S.A., Jabeen, A., Allai, F.M., Makroo, H.A. and Wani, S.P. 2022. Dried foods: Science, shelf life, and quality (pp. 141-154), in Shelf Life and Food Safety, CRC Press, Boca Raton.
Amer, B.M., Azam, M.M. and Saad, A. 2023. Monitoring temperature profile and drying kinetics of thin-layer banana slices under controlled forced convection conditions. Processes, 11, 1771.
Komonsing, N., Reyer, S., Khuwijitjaru, P., Mahayothee, B. and Müller, J. 2022. Drying behavior and curcuminoids changes in turmeric slices during drying under simulated solar radiation as influenced by different transparent cover materials. Foods, 11, 696.
Hu, Y., Zeng, X., Jiang, K., Luo, Y., Quan, Z., Li, J. and Zhu, B. 2024. Effect of non-enzymatic browning on oysters during hot air drying process: Color and chemical changes and insights into mechanisms. Food Chemistry, 454, 139758.
Roy, J., Leake, M.E., Barsha, A.S., Sherpa, T.L., Adebowale, A., Heda, G. and Yarborough, L. 2015. Thin layer chromatographic analysis of stability of curcumin and curcumin in turmeric after refluxing in water and using double mobile phase after heating in edible oils. Journal of the Mississippi Academy of Sciences, 60, 319–326.
Department of Agriculture, 2023, Academic documents: Turmeric Curcuma Longa L., Department of Agriculture, Horticulture Research Institute, Thailand [Online] Available: https://www.doa.go.th/hort/wp-content/uploads/2023/02/เอกสารวิชาการ-ขมิ้นชัน-กลุ่มวิชาการ-สวส.pdf. [30 July 2025].
