Performance Enhancement of a Close-loop Thermosyphon Boiler via the use of Water-ethanol Mixtures

Authors

  • Anuwat Bumrungkij Department of Mechanical Engineering, Faculty of Engineering and Architecture, Rajamangala University of Technology Suvarnabhumi, Phranakhon Si Ayutthaya, Thailand
  • Thanaphol Sukchana Department of Mechanical Engineering, Faculty of Engineering and Architecture, Rajamangala University of Technology Suvarnabhumi, Phranakhon Si Ayutthaya, Thailand

Keywords:

Boiler, Thermosyphon, Ethanol, Performance, Mixing Ratio

Abstract

The present study investigated the effect of mixing ratio of ethanol in distilled water, which was used as the mixed working fluid in a closed-loop thermosyphon boiler (CLTSB). The objective was to evaluate the heat transfer performance in relation to the ethanol mixing ratio. The evaporator of the CLTSB has a volume of 95 percent of the total system volume. A vapor line and liquid return line are made of copper tubes, with an internal diameter of 20 mm. Ethanol-distilled water mixture ratio was varied in the range of 10-90%; constant heat flux in the range of 50–300 kW/m2 was tested. The water-cooled condenser, operated at a constant inlet temperature of 25 °C and a constant mass flow rate, was used. The results showed that the ethanol mixing ratio of 40% helped increase the heat transfer performance when the value of heat flux was lower than 200 kW/m2. In contrast, when the ethanol mixing ratio was higher than 40%, the enhancement effect was lower with increasing mixing ratio.

References

Sukchana, T., 2020, “Design, Cons- truction and Testing of a Horizontal Thermo- syphon Boiler,” KMUTT Research and Development Journal, 43 (1), pp. 67–78. (In Thai).

Jaiboonma, C. and Sukchana, T., 2020, “Optimum Water Filling Ratio for a Closed Loop Thermosyphon with Evaporator as a Boiler,” Journal of Science and Technology Mahasarakham University, 39 (2), pp. 645-652. (In Thai).

Chehade, A.A., Louahlia-Gualous, H., Le Masson, S., Victor, I. and Abouzahab-Damaj, N., 2014, “Experimental investigation of Thermosyphon Loop Thermal Performance,” Energy Conversion and Management, 84, pp. 671-680.

Aghel, B., Rahimi, M. and Almasi, S., 2017, “Heat Transfer Enhancement of Two‑ phase Closed Thermosyphon using a Novel Cross‑flow Condenser,” Heat Mass Transfer, 53, pp. 765-773.

Jafari, D., Marco, P.Di., Filippeschi, S. and Franco, A., 2017, “An experimental Investigation on the Evaporation and Conden- sation Heat Transfer of Two-phase Closed Thermosyphons,” Experimental Thermal and Fluid Science, 88, pp. 111-123.

Lataoui, Z. and Jemni, A., 2017, “Experimental Investigation of a Stainless Steel Two-phase Closed Thermosyphon,” Applied Thermal Engineering, 121, pp. 721-727.

Naresh, Y. and Balaji, C., 2017, “Experimental Investigations of Heat Transfer from an Internally Finned Two Phase Closed Thermosyphon,” Applied Thermal Engineering, 112, pp. 1658–1666.

Naresh, Y. and Balaji, C., 2018, “Thermal Performance of an Internally Finned Two Phase Closed Thermosyphon with Refrigerant R134a: A Combined Experimental and Numerical Study,” International Journal of Thermal Sciences, 126, pp. 281-293.

Kima, Y., Shina, D.H., Kima, J.S., Youb, S.M. and Leea, J., 2018, “Boiling and Condensation Heat Transfer of Inclined Two-phase Closed Thermosyphon with Various Filling Ratios,” Applied Thermal Engineering, 145, pp. 328-342.

Chen S. and Yang J., 2016, “Loop Thermosyphon Performance Study for Solar Cells Cooling,” Energy Conversion and Management, 121, pp. 297-304.

Gedik E., 2016, “Experimental Inves-tigation of the Thermal Performance of a Two-phase Closed Thermosyphon at Different Operating Conditions Engine,” Energy and Buildings, 127, pp. 1096-1107.

Kannan, K. and Kamatchi, R., 2020, “Augmented Heat Transfer by Hybrid Thermosyphon Assisted Thermal Energy Storage System for Electronic Cooling,” Journal of Energy Storage, 27, pp. 1-10.

Sukchana, T. and Pratinthong, N., 2017, “Effect of Bending Position on Heat Transfer Performance of R-134a Two-phase Close Loop Thermosyphon with an Adiabatic Section using Flexible Hoses,” International Journal of Heat and Mass Transfer, 114, pp. 527-535.

Long, Z.Q. and Zhang, P., 2012, “Impact of Cooling Condition and Filling Ratio on Heat Transfer Limit of Cryogenic Thermo-syphon,” Cryogenics, 52 (1), pp. 66-76.

Long, Z.Q. and Zhang, P., 2013, “Heat Transfer Characteristics of Thermo-syphon with N2–Ar Binary Mixture Working Fluid,” International Journal of Heat and Mass Transfer,” 63, pp. 204-215.

Downloads

Published

2022-12-31

How to Cite

Bumrungkij, A., & Sukchana, T. (2022). Performance Enhancement of a Close-loop Thermosyphon Boiler via the use of Water-ethanol Mixtures. Science and Engineering Connect, 45(4), 469–482. retrieved from https://ph04.tci-thaijo.org/index.php/SEC/article/view/10325

Issue

Section

Research Article
